SKF ROLLER CHAIN 1-1/4- 100H -1 ROW -10FT BOX

ASA (1-1/4 INCH) PITCH HEAVY DUTY- SINGLE ROW
Stock Code:
PHC100H-1-BOX
$448.61 incl GST

Stock Locations

  • Ballarat:
    30 In Stock
  • Shepparton:
    6 In Stock
Make an Enquiry
Add to Favourites

Description

PHC 100H-1X10FT

SIMPLEX CHAIN, ANSI

Chains are critical components in power transmission systems. Robust, quality chain drives extend mean time between failures, which reduces maintenance costs. SKF chains are manufactured in state-of-the-art facilities with tight quality controls.

  • Provide a strong chain
  • Cost-effective
  • Reduce maintenance
  • Extend the mean time between failures
  • All products conform to ISO, and standards including ANSI, DIN and JIS

We stock British & American standards, with Double pitch, stainless steel and heavy variants also available.

Dimensions

Pitch31.75 mm
Roller diameter max19.05 mm
Width between inner plates min18.9 mm
Pin diameter max9.53 mm
Plate height max30 mm
Plate thickness max4.8 mm

Properties

Chain number100H-1
StandardANSI
TypeRoller chain
Weight per meter4.52 kg

Logistics

Product net weight13.8 kg
eClass code23-17-04-90
UNSPSC code26111505

Click here for catalogue information

View product table

SKF Chain Calculator


Product Guide Attached

Still can't find what you're looking for? Our website is being continuously updated, so contact us by phone or email for anything else:

Phone:
03 5336 1111

Email:
online@iw.net.au

Details

  • Material:
    STEEL
  • Brand:
    SKF
  • Metric/Imperial:
    Imperial
  • Number of Rows:
    1
  • Pitch:
    1-1/4 Inch
  • Chain Series:
    AMERICAN (ANSI)
  • Type:
    10FT BOX
  • Chain Size:
    100H-1 HEAVY DUTY (SINGLE ROW)
