W/A SHFT 6SER 1.5M 60LESS YOK

Stock Code:
WE6150_BARECO
$1,108.44 incl GST

Stock Locations

  • Ballarat:
    Special Order
  • Shepparton:
    Special Order
1 On Order
Make an Enquiry
Add to Favourites

Description

WE6150 BARECO

Wide Angle Shaft 1.5mtr (60") with One End Yoke WB6 Series

Wide Angle (C.V.) Shaft.

Dimensions

160 (63") Closed Cross to Cross Shaft Length,

260cm (102") Open Cross to Cross Shaft Length,

175cm (70") Closed Overall Shaft Length,

275cm (109") Open Overall Shaft Length.

WB6 Shaft Series,

27mm (1 1/16") x 32mm (1 1/4") Triangle Drive Tube,

Power Raiting:

48KW-64HP @ 540 rpm,

77KW-100HP @ 1000 rpm.

1 3/8" x 6 spline yoke on wide angle end.

No end yoke on the plain end.

Will accept standard yoke.

Non wide angle end yoke = standard BARE-Co 6 series.

80�� Wide Angle Joint On Inner Tube End.

For shafts with Wide Angle Joint both ends, select additional joint from Wide Angle Joint Page.

Warning! 80 degree Short Term Operation and Stationary 25 degree Continuous Operation Exceeding 80 degree angle will result in joint ball / socket FAILURE !

NOT COVERED BY WARRANTY.

Tractor turning limiter should be fitted to the implement drawbar.
