SKF Blue FoodLine Stainless Steel Insert Brg

20 X 47 X 31 / 14 Food grade YAR 204-2LPW/SS
Stock Code:
YAR204-2LPW/SS_SKF
$146.03 incl GST

Stock Locations

  • Ballarat:
    47 In Stock
  • Shepparton:
    Special Order
150 On Order
Make an Enquiry
Add to Favourites

Description

YAR204-2LPW/SS

SKF Blue Line Stainless Steel Insert Bearing

20 X 47 X 31 / 14 (Food grade H1 Grease)

At the heart of each unit is a high-quality corrosion resistant insert
bearing with AISI grade 420 stainless steel inner ring, outer ring and
balls. The Blue Range bearing units also incorporate a patented
bearing sealing system that adopts a radically different approach to
preventing damage caused by detergent ingress into the bearing

The bearing is designed as a single row deep groove ball bearing with a sphered (convex) outer surface to the outer ring. The sphered surface matches a correspondingly sphered, but concave housing bore. The design minimises internal loads on the bearing that would exist if initial misalignment went uncorrected.

The bearing inner ring is extended on the outboard/locking side. It is locked on the shaft with two stainless steel grub screws that are positioned at 120°, minimising inner ring distortion while maintaining good gripping strength. The inner ring of the bearing is dimensioned to accommodate the fitting of the back seal, allowing the units to be deployed in applications with the highest hygienic design and food safety requirements (e.g. open food processing zones). The sealing system consists of a non-contacting seal and a flinger, located at the outer circumference (fig 1). The flinger provides the first barrier against the ingress of both solid and liquid contaminants. This closes against the bearing outer ring when pressure washed.

Next, the design provides a series of internal concentric “gutters” (fig. 2) which contain and collect any drops of detergent that penetrate and then guide them, circumferentially, around and away from the bearing (fig. 3).

Due to this innovative design, the sealing performance is not limited by the lip contact force against the shaft. This means that the seal can achieve high levels of protection coupled with low energy consumption. The internal gutters are designed to guide detergent away from the bearing. Whereas the aim of a detergent is to penetrate and clean, this novel approach aims to work with rather than against the detergent.

Dimensions

Bore diameter20 mm
Outside diameter47 mm
Width, total31 mm
Width, inner ring31 mm
Width, outer ring14 mm

Performance

Basic dynamic load rating10.8 kN
Basic static load rating6.55 kN
Limiting speed5 000 r/min
NoteLimiting speed with shaft tolerance h6

Properties

Retaining feature, inner ringSet screws
Bore typeCylindrical
Rolling elementsBalls
Outer ring typeSpherical
Inner ring extensionOn both sides
CageNon-metallic
Rubber seating ringWithout
Material, bearingStainless steel
CoatingWithout
SealingSeal and flinger on both sides
Sealing typeContact, gutter
LubricantGrease
Relubrication featureWithout

Logistics

Product net weight0.147 kg
eClass code23-05-08-02
UNSPSC code31171536

Click here for catalogue information

View product table


Product Guide Attached

Still can't find what you're looking for? Our website is continuously being updated, so contact us by phone or email for anything else:

Phone:
03 5336 1111

Email:
online@iw.net.au

Details

  • Bore Size:
    20 mm
  • Material:
    Stainless Steel
  • Width:
    14 / 31 mm
  • Brand:
    SKF
  • Metric/Imperial:
    Metric
  • Type:
    Blue Line Food Grade Series
  • Size:
    204
  • Diameter Outside:
    47 mm
  • Style:
    Food Grade Grease
