SKF - Cylindrical Roller Bearing Brass Cage

95 x 170 x 32 (NUP 219 ECM/C3)
Stock Code:
NUP219ECM-C3_SKF
$986.71 incl GST

Stock Locations

  • Ballarat:
    1 In Stock
  • Shepparton:
    Special Order
Make an Enquiry
Add to Favourites

Description

NUP219ECM C3

Single row cylindrical roller bearing, NUP design

Single row cylindrical roller bearings are designed to accommodate high radial loads in combination with high speeds. Having two integral flanges on the outer ring and one integral flange and one loose flange ring on the inner ring, NUP design bearings can locate the shaft axially in both directions. An important feature is the separable design, which facilitates mounting and enables the bearing components to be interchanged.

  • High radial load carrying capacity
  • Low friction
  • Long service life
  • Locate the shaft axially in both directions
  • Separable design

Dimensions

Bore diameter95 mm
Outside diameter170 mm
Width32 mm

Performance

Basic dynamic load rating255 kN
Basic static load rating265 kN
Reference speed4 300 r/min
Limiting speed4 800 r/min
SKF performance classSKF Explorer

Properties

Bearing partComplete bearing
Axial displacement capabilityNone
Number of rows1
Locating feature, bearing outer ringNone
Bore typeCylindrical
CageMachined metal
Number of flanges, outer ring2
Number of flanges, inner ring1
Loose flangeInner ring loose flange
Radial internal clearanceC3
Tolerance classNormal
CoatingWithout
SealingWithout
LubricantNone
Relubrication featureWithout

Logistics

eClass code23-05-09-01


Click here for catalogue information

View Product Table

Product Guide Attached.

Still can't find what you're looking for? Our website is continuously being updated, so contact us by phone or email for anything else:

Phone:
03 5336 1111

Email:
online@iw.net.au

Details

  • Bore Size:
    95 mm
  • Material:
    Brass Cage
  • Width:
    32 mm
  • Brand:
    SKF
  • Metric/Imperial:
    Metric
  • Number of Rows:
    Single Row
  • Type:
    NUP - Outer 2 flanges - Inner 2 flanges
  • Size:
    219
  • Diameter Outside:
    170 mm
  • Style:
    Open
